16 Port DB-15 KVM Switch – AR-V16L

• Angustos AR-V16L LCD KVM Switch is optimized for high density Rack in modern Data Center.
• A KVM Switch with 16 ports and supports computers with PS/2 or USB interfaces via cables. All packed in a 1U rackmountable metal housing. The short-depth design ultilized for narrow space for short-rack mounting in condensed area. The AR-V16L can control up to 16 computers; with 512 additional KVM switches are cascaded on 2 level, a single AR-V16L KVM Switch can control up to 16384 computers.
• In addition, the AR-V16L included the computer selection via front panel pushbuttons, hotkeys and OSD. With all of the technology involved, the AR-V16L LCD KVM Switch has gone beyond the expectations and requirements for a modern Data Center use, which including : short space optimization, exceptional display quality, easy to install, extreme versatility.

High Density Utilization

• One direct USB – PS/2 console controls 16 computers. Does not require special console cable.

• Dual interface supports with computers with PS/2 or USB keyboards and mice.

• Short-depth overall size allowing user to work with in condensed space of high density Rack

• Multiplatform support: compatible with all operation platforms PC (Windows,Linux and most others), Mac and Sun.

Flexible compatibility

• Superior video quality – up to 2048×1536 @60Hz;

DDC2B; 16.7 Mil. Color. Auto detecting EDID info.

• Cascade up to 16384 computers from a single console (With compatible KVM Switches).

• Auto PS/2 and USB interface sensing.

• Keyboard and mouse emulation (PS/2 and USB) for seamless switching.

• Computer selection with pushbuttons, hotkeys, and multilingual on-screen display (OSD).

• Two level password security. Auto Scan function

• Multicast Mode – Operate command action at the same time for all connected computers.

• Operates with all software and operating systemsincluding all Windows versions, DOS, Linux, Unix, BSD, all Sun OS, all Mac OS and NetWare.

• Keyboard Language supports: English (UK), English (US), German (GER.) Japanese, Korean, Russian, Swedish, Chinese.

Installation Flexibility

• Standard rack mount kit included

• No software required – Plug and Play

• Firmware upgradable

• Supports hot-plugging
